PERFORMANCE ADVANGATE

1. Strong corrosion resistance: H44F fluorine-lined check valve adopts fluoroplastic lining, which

has excellent corrosion resistance and can resist corrosion from a variety of strong acids, strong

alkalis and strong oxidants.

2. Wide range of applications: The valve is suitable for a variety of media, including water, steam, oil,

nitric acid, acetic acid, strong oxidizing media and urea, etc.

3. Reliable sealing: The valve disc and shaft of H44F4 fluorine-lined check valve are designed as one,

and all fluorine-lined materials make opening and closing flexible and sealing reliable. Even in

low-pressure areas, good sealing performance can be guaranteed.

4. Long service life: Due to the use of corrosion-resistant fluoroplastic materials, H44F4 fluorine-lined

check valve has the characteristics of wear resistance and long service life.

TECHNICAL SPECIFICATION

Model:                                              H44J-16/H44F46-16

Working pressure :                          16 Bar

Working temperature:                      ≤80°C

Nominal size:                                   DN50-300

End connection:                               Double Flange

Design Standard:                             GB/T9113;JB/T82.1-82.4;HG20592

Face To Face:                                  ASME B16.10

Flange Drilling:                                 HG/T20592,ASME B16.5

Inspection And Test:                         API598

PRODUCT PARTS AND MATERIALS

Body Material:                                 Cast Iron,Cast steel,Stainless Steel Lined EPDM/NR/PTFE

Bonnet Material:                              Cast Iron,Cast steel,Stainless Steel Lined EPDM/NR/PTFE

Disc Material:                                  Cast Iron,Cast steel,Stainless Steel Lined EPDM/NR/PTFE

Gasket:                                            F4,F46
